FFG-VRIDA-TP AUTO HIGH SPEED PRINTER FOLDER GLUER INLINE
FFG-VRIDA-TP AUTO HIGH SPEED PRINTER FOLDER GLUER INLINE
  • Technical parameters
  • Product description
  • Download
  • Inquiry
  • Video

FFG-VRIDA-TP技(jì )术参数




Features:








  Fixed printing unit machine but openable –easy

     to do maintenance

◆  Integrated CNC control system, trouble-shooting,

      production  management, remote maintenance.

◆  Printing plate mounting when machine is running, quick

     spraying  anilox roll washing system.

◆  Fixed printing unit machine but openable –easy to do

     maintenance and add printing unit

◆  High precision transfer structure with ceramic vacuum

      transfer  wheel,good registration accuracy.

◆  Powerful dust remover, with anti-static bar, centralized dust

      collection,less ECT loss.

◆  Creasing-slotting unit, prevent creasing line from bursting,

      better folding.

◆  Counter ejector with down stacking.

◆ Choose international brand electric components and .

    transfer bearings,passCE certification








Main Console:














◆  Windows base CNC control system

◆  Remote maintenance

◆  Huge order saving

◆  Trouble-shooting

◆  Optimized order memory

◆  Production and order management

◆  Available to connect with the customer internal ERP






Feeding Unit:




◆  Operation can be controlled by both main console and each

      unit touch screen.

◆  Lead-edge feeding, adjustable air control, precious

     registration

◆  Precious liner guideway lateral moving

◆  Motorized side squaring and paper support

◆  Powerful dust remover, with anti-static device, centralized

     dust   collection,  less ECT loss.






Printing unit:







◆  Operation can be controlled by both main console and each

     unit  touch screen.


◆  High precious transfer structure with ceramics vacuum

     transfer  wheel, good registration accuracy.

◆  Printing plate mounting when machine is running,safety

     protect  cover synchronized lifting, quick and safe order change,

     productivity and efficiency.

◆  Quick printing plate mounting, motorized phase zero.

◆  Double doctor blade, quick spraying anilox roll washing and ink

     savingsystem.

◆ Fixed printing unit machine but openable –easy to do

    maintenance  andadd printing Unit





Dwell transfer Unit :




◆ Operation can be controlled by both main console and each

     unit touch screen.

◆ Dwell vacuum transfer, increase drying space,reduce the

     transfer  effect from slotter and die-cutter.

◆  Option: Infrared ray or UV dryers






Creasing Unit :




◆  Operation can be controlled by both main console and each unit

      touch screen.

◆  Liner guideway lateral moving device with universal cross joints.

◆  Precious ball screw shaft, high rigid guiding cast, long lifetime.

◆  Big Pre-creaser, Pre-creaser, big creaser, prevent creasing line

      from bursting,   better folding.

◆  Motorized gap control, large displacement of middle knife.






Slotting Unit :







◆  Operation can be controlled by both main console and each

      unit touch screen.

◆  Liner guideway lateral moving device with universal cross

      joints.

◆  Precious ball bearing, high rigid guiding cast, long life time.

◆  Box height motorized control

◆  Motorized gap control, large displacement of middle knife.










Die-cutting Unit :









◆  Operation can be controlled by both main console and each

      unit touch screen.

◆  Die-cutting roll pneumatic self-locking device.Die-cut

      pressure motorized control

◆  C.U.E quick change die-cut anvil with grinding mechanism.

◆  Precious settable speed difference compensation, ensure

     die-cutting accuracy.











Splicing section:









◆  Softener and rotary brush, fan assistant.

◆  Belt transfer











Folding gluing section :









◆ Constant temperature gluing system with big gluing wheel,

       reticulation gluing,  motorized control glue wheel position.

◆ High rigid folding beam, ensure folding precision

    and high speed stability.

◆ Guide-way linear movement, high rigid beam fixed on

    the ground.

◆ Elastic wheel, motorized pneumatic adjust gap,

    smooth transfer.

◆ Folding finalize wheel correct fish tail, gap motorized

    control.

◆ Folding belt motorized driven, correct folding difference.











Count-Ejector unit :









◆  High speed down counting stacking, prevent box smearing.

◆  Side squiring, pneumatic plat push.

◆  Several servo driven, high efficiency counting stacking.

◆  Count-ejector unit lateral move motorized control.











Graphic( FFG 920 ) :







FFG- VRIDA-TP Catalog positive online preview1
文(wén)件类型: .jpg fea2d862d1787b067385be1e657912f2.jpg (300.25 KB)



FFG- VRIDA-TP Catalog positive online preview2
文(wén)件类型: .jpg 59b23f422e9b2b376660349e803fb7c8.jpg (335.42 KB)




FFG-VRIDA-TP Click here to download the product catalog
文(wén)件类型: .zip static/file/文件类型 (518.65 KB)









 .
